GD 850
Detail Teknis
- Sudut penutupan pintu ≤ 120⁰
- Kecepatan penutupan maks. tetap
- Ukuran kekuatan pegas 3 atau ukuran 4
- Panjang 307mm
- Lebar 108mm
- Kecepatan penutupan dapat disesuaikan melalui katup
- Kecepatan penguncian dapat disesuaikan melalui katup
- Versi non-handed tersedia
- Tahan terbuka 90⁰
Komponen
- GD 850 floor spring
- Aksesoris AL
- Perlengkapan tambal sulam
- Kunci patch GS US 10
- Patch atas GD PT 20
- GD PT 10 patch bawah
- Patch panel atas GD PT 30 (opsional)
- Patch panel atas GD PT 40 (opsional)
Opsi Penyelesaian
- GD 850 Patch fittings finish in SSS or PSS
Deskripsi
dormakaba’s GD 850 Floor Spring Package is specially-designed for use in low traffic areas. The package, comprising of a floor spring and patch fittings, is able to satisfy the basic requirements of glass doors that open in both inward and outward directions.
GD 850 is suitable for use with standard double-action doors with door widths of up to 1050mm and maximum door weights of 85kg.
